EWD-L-BMSJ4 intelligent elevator weighing device Manual
Villa Elevator User’s Guide
EWD-L-BMSJ4
Xi’an Excellent Electromechnical Co.,Ltd
(V2.2)
EWD-L-BMSJ4 intelligent elevator weighing device Manual
Page 2 of 30
Table of Contents
Product
Overview
1.“EWD-L-BMSJ4”The main functions and characteristics of the weighing device
2.“EWD-L-BMSJ4”Installing Method and Working Principle
……
3.Product Appearance and Type Nomination
……
4.Controller interface diagram and description
……
5.Controller dimensions
……
Installation &
Adjustment
6.Button function and instruction code meaning description
……
7.System debugging methods and instructions (self-learning)
……
1).Elevator Rated load rang setting
……
2).No-load self-study mode of work
……
3).The amount of self-learning work mode
……
8.Multiplier parameter setting and description (auxiliary function)
……
System
Characteristics
9.Technical Specifications
……
Promise
……
Other
Attached sheet
……
Note: This system is applicable to all traction drive or reel drive villa elevator, please read the following sections carefully before use.
Notice: In any case, we are only responsible for the quality of the products under warranty.
Statement: Due to technological progress, the company reserves the right to change the product; For technical specifications, refer to
EWD-L-BMSJ4 intelligent elevator weighing device Manual
Page 3 of 30
the manual delivered with the product.
System Overview
一
.
“EWD-L-BMSJ4”The main features of the weighing device:
1. The normal work of the product, the direct display of the car internal payload, self-learning process is
simple.
2. Intelligent programming and control process, according to different customer needs, the controller output
of the 4-way switch signal in any one of the signal corresponding to the percentage of load and dynamic /
dynamic output adjustment, and the output simulation The amount of the way to modify.
3. Intelligent sensor equipment: the use of high-precision load intelligent sensor, direct detection of car load
changes;
4. Wide measurement range (payload can be manually set according to demand), high positioning accuracy,
intelligent temperature compensation.
5. Electrical performance in line with the "International Electrotechnical Commission (IEC)" standard
requirements;
6. The core uses high precision load cell and high performance single chip microcomputer. Can set all the
working parameters.
7. Unique programmable output signal control mode, suitable for a variety of activities of the car to mention
the elevator weighing signal on the demand.
8. With the working parameters of artificial fine-tuning correction ability, the elevator can be modified after
the artificial correction, so as to achieve the purpose of accurate measurement.
9. Unique sensor + controller design structure, wiring is simple.
10. Everything from the user point of view, easy to install, easy to debug, reduce the use of additional costs,
performance and high cost.
二
.
“EWD-L-BMSJ4”working principle：
With the continuous progress of elevator technology, elevator weighing device on its performance has been
EWD-L-BMSJ4 intelligent elevator weighing device Manual
Page 2 of 30
to the point where it can not be ignored. Elevator on the weighing device of high precision, high reliability,
multi-functional needs are imminent. In the sensor technology and micro-computer continues to develop today,
the use of high-precision rubber sensor to detect the elevator car due to load changes caused by electrical signals.
High precision rubber sensor: the use of serial communication technology for its long-distance high-precision
non-destructive transmission; sensor comes with 8 ~ 10m signal transmission cable; at the same time using the
microcontroller microcontroller to its scientific computing, the final precision Directly in the controller digital
display shows the car inside the payload, to achieve the elevator car payload weighing work function.
三
. Controller and load sensor Appearance
：
1. Elevator load weighting device“EWD-L-BMSJ4”Controller
Model
EWD-L-BMSJ4
Elevator load weighting
device“EWD-L-BMSJ4”
Controller
EWD-L-BMSJ4 intelligent elevator weighing device Manual
Page 3 of 30
2. Sensor selection and installation
：
Load sensor
Model
XCL-Y/3411
XCL-YH/5018
XCL-Y/5222
XCL-ZL/W
Dimensions
ss
see attachment
see attachment
see attachment
see attachment
Load sensor
Model
XCL-T/A（20)
XCL-T/B（20)
XCL-ZL/P2
XCL-ZL/P3
Dimensions
see attachment
see attachment
see attachment
see attachment
EWD-L-BMSJ4 intelligent elevator weighing device Manual
Page 2 of 30
四. Controller interface diagram and description：
1. Controller interface diagram
：
2.Controller port details
：
EWD-L-BMSJ4 intelligent elevator weighing device Manual
Page 3 of 30
Function
Explanation
PJ
Switching
1
J1Relay COM port
With the P2 to produce effective logic
1. Function：Be
programmed as“J1～
J4”(No load - over
load)output signals to
participate in elevator
logic control
2.Max loading
Capacity：
DC/AC 48V/500mA
2
J1 Relay Output
System default“J1”:5Kg No load Dynamic open
output；
3
J2、J3、J4 Relay com port
With P4.P5.P6，to produce effective logic
4
J2 Relay Output
system default“J2”：Light load Dyn. Close output
5
J3 Relay Output
system default“J3”：Related load Dyn close output；
6
J4 Relay Output
system default“J4”：Overload Dyn,open output；
PM
Lock
1
Lock signal COM prot
Note the voltage difference and the connection polarity when connecting
2
DC+24V lock signal，Can
access the door lock
signal and brake signal
PX
Analog
3
0～10V;10～0V;Analog
voltage output
Used for pre-torque compensation of the drive system
4
COMConnect the
governor to the analog
common
PV
Power supply
System power supply port：AC/DC 24V／200mA
PG
Sensor
connection
port
PG1 PG2 PG3
PG4PG5PG6
EWD-L-BMSJ4 controller
Connect to PG1-PG4 ports based on the number of sensors.
①It is absolutely impossible to connect the output port other than the "PV" device directly to the
external power supply, which may cause permanent damage
(Note：PXandPMPorts have polarity requirements and voltage level requirements)
EWD-L-BMSJ4 intelligent elevator weighing device Manual
Page 2 of 30
五. Size of Controller：
EWD-L-BMSJ4 intelligent elevator weighing device Manual
Page 3 of 30
Precautions for controller and sensor installation:
1. The controller part should be installed in the control box on the top of the car, and it is best not to be close to
the transformer, governor and other equipment of the elevator electric control system.In any case, the sensor and
controller should be installed away from the heat source;
2.4 sensors or 6 sensors should be installed on the bottom of the car and connected to the controller. It is better not
to be in the same wiring groove with power sources such as 110V and 220V.
3. Connect the sensor connection port to the PG port of the controller, and connect PV to the power cord
according to system requirements.
After making sure that the system is energized, the controller should display the corresponding working mode
4.After making sure that the system is energized, the controller should display the corresponding working mode
六．Button Function and Instruction Parameter Code Meaning description：
Note：（1）.Press the button, the meaning is to press the button to release.
(2) Hold down the button, meaning that the button is pressed for a long time as required.
1. Button Meaning and Function Description
：
No.
Button icon
Function
Explanation
EWD-L-BMSJ4 intelligent elevator weighing device Manual
Page 2 of 30
1
【■】
Set and confirm Button
（SET）
Set a parameter and confirm the
internal data function
2
【 】
Switch / cursor shift
Button(SHIFT)
Used to switch the digital display
digit
3
【▼】
Data increase Button
（ADD）
Change the internal value of the
parameter
2.Button to use method description
：
⑴
Set and confirm button
【
■
】
Instructions
：
When power is displayed, press it【■】，Enter the parameter setting status，by【 】 and 【▼】button Enter
the setting parameter，Can be set accordingly。Finish setting ，press【■】button check，Save the parameters。
⑵
Switch / cursor shift buttons
【 】
Instructions
：
In the parameter setting state，press once【 】，The cursor moves one by one ，to the last one，Press the
toggle / cursor shift button【 】And cycle back to the first place.
⑶Data increase button【▼】Instructions：
In the parameter setting state，press once【▼】，Add one to the cursor bit data, add the maximum value of the
set data and then cycle back to the minimum value of the data.
3.With the decimal point of the parameters of the process of adjusting the use of key
examples:
EWD-L-BMSJ4 intelligent elevator weighing device Manual
Page 3 of 30
After powering on the product, press 【■】 button to enter the instruction setting state. When "00000" is
displayed, press 【 】button to move the flashing cursor to the last digital tube. Press 【▼】 key to adjust the
digital display to "00001", press【■】button to enter the command parameter setting state, digital display "dd - c",
press 【■】 buttons to enter this Parameter modification mode, display "00001" means that the decimal point is 1
bit. Press【 】and【▼】to change the digital tube display to "00002", press【■】key to confirm this parameter
is modified, the digital tube decimal point will move one by one. (Note: other instruction item parameters can be
modified and confirmed in accordance with this method.)
3.Instruction Parameter Code Meaning Description：
No
Instruction
parameter code
Function
code
Code default
data
Function and explanation
1
00001
dd--c
00001
Display the decimal point position setting,
the factory default for the 1-bit display
"00001", adjustable 4 decimal point
adjustment
2
00002
Lc--01
1000.0
The amount of load range set, according to
the different capacity of the elevator directly
to the manual set to the load range can be。
3
00003
Bj--1
0005.0
J1 for the no-load signal output
corresponding to the car load, the default
setting elevator car load 5.0kg:
Bj--2
0005.0
J2 for the light load signal output
corresponding percentage, the default
EWD-L-BMSJ4 intelligent elevator weighing device Manual
Page 2 of 30
setting for the amount of 5% output action,
BJ--3
0090.0
J3 for the full load signal output
corresponding percentage, the default
setting for the amount of 90%,
BJ--4
0105.0
J4 for the overload signal output
corresponding percentage, the default
setting for the amount of 105%,
4
00004
BJ-HL
BJ1-L
J1 relay dynamic output, dynamic (L) /
moving (H) adjustable
BJ2-H
J2 relay moving output, moving off (L) /
moving together(H)adjustable
BJ3-H
J3 relay moving output, dynamic (L) /
moving (H) adjustable
BJ4-L
J4 relay dynamic output, dynamic (L) /
moving (H) adjustable
5
00005
Da--c
Da-00
Analog output mode corresponds to P9 ~
P10 terminal port output 0 ~ 10V,
Da-01
Analog output mode corresponds to P9 ~
P10 terminal output 10 ~ 0V,
6
00006
HELP-
---01
Restore factory settings
EWD-L-BMSJ4 intelligent elevator weighing device Manual
Page 3 of 30
7
00007
B2--c
B2-01
Multiplier parameter setting, multiplied by
the amount of 1 times, "01 ~ 99" value
corresponding to the amount of 1 to 99
times the amount of adjustable; ★ multiplier
parameters to be modified after the
completion of self-learning after the
completion of confirmation
8
00008
L-H-2
LL--1
The controller learns the no load parameter;
HH--1
The controller self - learns the load
parameter
9
00009
l-h-2
1000.0
Fine-tuning the coefficient setting to
fine-tune the learning results
七、System debugging methods and instructions (self-learning)：
（Here to lift the amount of 1000Kg as an example to describe the load range setting and "no load and the
amount of two self-learning" process）
Before the system debugging：
①：Products must be in strict accordance with the "EWD-L-MSJ4 user manual" for self-learning, otherwise it
will cause the product can not be used and product measurement accuracy is not accurate.
②：Before commissioning, it is necessary to specify the weight of the car. The weight of the truck can not
EWD-L-BMSJ4 intelligent elevator weighing device Manual
Page 2 of 30
exceed the total range of the sensor. Otherwise, the sensor will be damaged and the product will not be used.
1.Elevation range setting
：
Note
：①
1. Product digital tube display the default decimal point to
1, the unit is Kg, For example :the case shows "1000.0", that is 1000kg.
2.No-load self-learninocess
：
Note：① product no-load self-learning before the car must ensure that there is no load and debris,
otherwise it will lead to a greater error in the weighing effect.
② product no-load - the two-point self-learning process, must be "LL-01" first study no-load, "HH - 1"
retraining, otherwise it will lead to the product can not be used
1.Check that the sensor wiring is correct;
2. Confirm the signal grade and polarity of the product terminals,
and after the plug is firmly connected, the product is powered on
and the digital tube is displayed normally。
NO
System digital tube normal display ，press【■】Set the key to enter the command
selection state，When show “00000”，press【 】and 【▼】button Change the
digital tube display to“00002”After the load range setting command，press【■】，
when show“Lc--01”，press again【■】Enter the load scale to modify the state，press
【 】and 【▼】Change the digital tube display to“1000.0”，press【■】Confirm
and save the range of 1000Kg of data。（Example: elevator capacity of 1000kg, that is,
the amount of load range set to 100% of the amount of "1000.0" can)
Ensure that the power supply circuit and the sensor are connected
properly after power supply。
yes
Restore factory default method：
Double-click the quick recovery method：Turn on the power，press
same time【 】and 【▼】10slater，when show“HELP-”，The
internal setting has been restored to the factory settings。
Instruction parameter confirmation method：Turn on the power，press
【■】，enter“00000”Command selection interface，press【 】
and 【▼】Change the digital tube display to“00006”，press【■】
enter“help-”，press again【■】，to restore the factory settings.
yes
yes
EWD-L-BMSJ4 intelligent elevator weighing device Manual
Page 3 of 30
Contact power supply，press【■】Enter the command selection state，when show“00000”，
press【 】and 【▼ 】Change the digital tube display to“00008”，press 【■】，when
show“L-h-2”，press【■】to enter the command parameter modification state，when show
“LL-01”，In the car when no load，press【■】to confirm and save the load data of the empty
car at this time。保 Save success show "HH - 1", thus no longer successful learning.
Has been successfully completed the
elevator rated load range set, the
elevator car weight and rated load no
longer change。
Yes
No
Elevator due to late decoration, car weight
has changed, or because the customer
needs to modify the rated load.
Follow the first step to complete the elevator scale setting operation.
yes
NO
EWD-L-BMSJ4 intelligent elevator weighing device Manual
Page 2 of 30
3.Lift the amount of self-learning process：
After successful completion of the no-load
self-learning process, add 100% of the load
weight to the elevator car when the product
"HH-1" is displayed. (For example, this elevator
is set to 1000Kg, The weight of the weight of
1000Kg), press the 【■】 key to confirm and save
the load data of the car. When the digital display
"1000.0", this time shows the car is the actual
load value, the flag from the self-learning
completion.
Digital display of the current load data, this
mark the product from the successful study,
into the normal working condition.
No
Due to self-learning misuse (elevator load and
weight changes), resulting in digital tube display
weight and car load does not match or the error is
too large, you need to restore the factory settings,
re-self-learning.
Restore factory default method：：
1
Double-click the quick recovery method：Turn on the power，
press same time【 】and 【▼】10slater，when show“
HELP-
”，
The internal setting has been restored to the factory settings。
2 Instruction parameter confirmation method：Turn on the power，
press【■】，enter“
00000
”Command selection interface，press
【 】and 【▼】Change the digital tube display to“
00006
”，
press【■】enter“help-”，press again【■】，to restore the
factory settings.
yes
yes
EWD-L-BMSJ4 intelligent elevator weighing device Manual
Page 3 of 30
八、Multiplication parameter setting process description (auxiliary function)）：
Note ： Repeated parameter debugging must be in the product after the completion of Chapter 8 product
self-learning process before they take effect. Multiplier parameter adjustment range of "01 ~ 99", that
is, the product multiplier for the amount of 1 to 99 times the amount for customers to choose. The
product default multiplier parameter value is 1 times the amount of time to restore the factory settings
after the product multiplier parameters are restored to the product default multiplier parameter value of
the rated load of 1 times.
1.Multiply parameter setting process：
2.For Example
：
When the system is normally displayed, press the " ■ " key to enter the command selection state. When
"00000" is displayed, press the "【】 key and [▼] to modify the display of the nixie tube to" 00007 ". Press the "
■" key, and when "BZ--C" is displayed, press the "■" key again to enter the command parameter modification
state. Product digital display "BZ-01" (the last two digital tube display "01" is the multiplier multiple, such as the
multiplier parameter value of "05", at this time the elevator load multiplied 5 times, product output switch quantity
and analog quantity will make the corresponding doubling changes) press [▼] the key to modify the digital tube
display to the required times value-added, Press ■ to confirm and save the multiplication parameter.
When the system is displayed normally,Press 【 ■ 】 to enter the instruction selection state, and when
"00000" is displayed；press【 】and【▼】button to change the digital tube display to "00007".
"Press【■】key to display "bz - c", press the【■】key again to enter the command parameter
to modify the state, the product digital hanging display "bz-01" (after the two digital display
"01" That is doubled, for example
EWD-L-BMSJ4 intelligent elevator weighing device Manual
Page 2 of 30
System Features
十、
Technical Specifications
：
⒈
Application：
eing applicable to all fixed car platform elevators
⒉
Floor Compensation
Artificial changes in learning errors and fine-tuning.
⒊
Sensitivity：
Elevator Rated Capacit/1000 (Example： The rated capacity is 1000 ㎏, and the
sensitivity is 1 ㎏ ) [This data may be affected by elevator mechanical
performance.]
⒋
System Error：
≤0.25％（-20～55℃）
⒌
Non-Linearity：
≤0.25％
6.
Output Mode：
Programmable
4-way switch
signal：
①4-channel programmable output modes are: No load, light load,
rated load, overload (customer may set the changing range freely).
②Each channel can be programmed as dynamic Close or Open
contact.
③Contact Capacity：DC/AC 48V/100mA。
Linear
analogue：
Full compensation range 0～10V;10～0V
7
Ambient
Temperature：
-20～55℃
8.
Relative Humidity：
20%～90％RH
9.
Reaction Time：
≤0.25senconds
EWD-L-BMSJ4 intelligent elevator weighing device Manual
Page 3 of 30
10.
Power supply：
AC/DC24(±10%)V／200mA
11.
installation Place：
Load sensor：See attachment sheet
Controller：Control Cabinet in machineroom
12.
Overall Size：
Controller parts：115×90×40 mm3
The intension exceeding the limit parameters listed above may result in the abnormality or
permanent damage to the system.
Promise
⑴If this system appears any quality problem of product itself in 1 year after delivery, it will be
replaced freely（damage of the product seal will not be dealt with）。
⑵For any requirement of special functions, make it out by mail.
⑶Any system abnormality in adjustment or operation, please contact our company directly.
Other
Packinglist：
EWD-L-BMSJ4 Controller
1piece
Φ4×40mm Fastening Screw sets
4sets
Load sensor
1piece
User’s Guide 1piece
⒉Address:
Xi’an Excellent Electromechnical Co.,Ltd
7D ， Block A, Olympic Building, 14th Chang An North Road, Xi'an,
Shaanxi,China.
：
(029)88416613 (029)85565714-886
Technical Support：0086-180926397
50 008618092639752
：
710061
EWD-L-BMSJ4 intelligent elevator weighing device Manual
Page 2 of 30
Attched Document：
Load cell / tension sensor dimensions and installation
1.XCL-Y/3411 load sensor dimensions:
1.1 Sensor size diagram（measuring range：6KN,12KN）
Note: 2 supporting screws per set Supporting Screw
EWD-L-BMSJ4 intelligent elevator weighing device Manual
Page 3 of 30
Installation Methods:
Installation diagram 1 Installation diagram 2
Note: When the user makes the splint, the distance A should equal
the distance B.
注意：用户自制夹板时，A距离应等于B距离。
A
B
70
3-Φ6
均布
2-支撑螺钉
上绳头板
下绳头板
传感器
11
Φ26
2-M8
上绳头板
下绳头板
Φ
62
3-
Φ
16
均布
3-
Φ
6.5
均布
传感器
Φ
26
11
EWD-L-BMSJ4 intelligent elevator weighing device Manual
Page 2 of 30
2.XYL-YH/5018-15KN load sensor dimensions:
2.1 Sensor size diagram （measuring range：15KN）
2.2 Installation Method:
EWD-L-BMSJ4 intelligent elevator weighing device Manual
Page 3 of 30
3.XCL-Y/5222 load sensor dimensions:
3.1 Sensor size diagram （measuring range：6KN) :
Φ
4
4
7
22
Φ10
Φ52
4-M5（深8）
均布
4芯带屏蔽线缆
长度：8米
配4-M5内六方圆柱头螺钉
GB/70.1-2000
70
100
Φ
25
22
GB/70.1-2000
配2-M5内六方圆柱头螺钉，L=8
9
2-M5
EWD-L-BMSJ4 intelligent elevator weighing device Manual
Page 2 of 30
3.2 Installation Method:
A
B
70
100
25
2-
Φ
9
4-
Φ
9
均布
45
30
Φ
44
压杆
上绳头板
下绳头板
传感器
22
EWD-L-BMSJ4 intelligent elevator weighing device Manual
Page 3 of 30
4.XCL-ZL/W load sensor dimensions:
4.1 Sensor size diagram （measuring range：15KN,8KN)
Note: During installation, be sure to use Ø6 wire rope to connect the safety ring and secure it on the support of the tractor,
in case the sensor falls off during installation and debugging, to ensure personal safety!
EWD-L-BMSJ4 intelligent elevator weighing device Manual
Page 2 of 30
4.2 Installation Method:
EWD-L-BMSJ4 intelligent elevator weighing device Manual
Page 3 of 30
5.XCL-T/A(20)load sensor dimensions:
5.1 Sensor size diagram （measuring range：12KN)
5.2 Sensor size diagram
38
50
2-M10
86
20
5
2-
Φ
8
100
11.5
EWD-L-BMSJ4 intelligent elevator weighing device Manual
Page 2 of 30
6.XCL-T/B（20)load sensor dimensions:
6.1 Sensor size diagram （measuring range：10KN)
6.2 Installation Method
100
86
44
50
20
7
7
2-M10
2-
Φ
6.5
24
18
70
下夹板
上夹板
EWD-L-BMSJ4 intelligent elevator weighing device Manual
Page 3 of 30
7.XCL-ZL/P2 load sensor dimensions:
7.1 Sensor size diagram （measuring range：5KN,8KN)
7.2 Installation Method
EWD-L-BMSJ4 intelligent elevator weighing device Manual
Page 2 of 30
8.XCL-ZL/P3 load sensor dimensions:
8.1 Sensor size diagram （measuring range：5KN,8KN)
8.2 Installation Method
